“Barometric damper” air inlet for room with woodstove

David Meiland|发布Mechanicals

Wondering if someone can identify a specific product for this application. The merits of the application might entice some to debate, but I am neither a code writer nor building inspector, just a guy caught between them.

我在艺术工作室空间里有一份木棍工作。它没有从火箱到外部气管的直接连接,这样做是很难且昂贵的,因为炉子在混凝土板上,它是在另一侧的墙壁上,it’s 12′ from any exterior wall.

The code states that if the stove is installed in existing construction on a slab, that combustion air can be supplied to the ROOM via a “barometric damper”. What I would like to do (and about the only thing I can do) is install some type of through-the-wall inlet with the aforementioned barometric damper within it. The American Aldes airlets do not qualify, per the language on their instruction sheets. There are barometric dampers intended for use with HVAC systems, typically involving a short section of round duct with a damper inside and a weighted arm outside, which can be adjusted for pressure. The problem with the arm outside is that it won’t easily fit in the wall, and putting on the inside of the room will be objectionable.

Anyone know of any sort of damper or valve that would work for this purpose? Ideal candidate would be 4″ or 5″ diameter.

GBA Prime

加入建筑科学专家的领先社区

Become a GBA Prime member and get instant access to the latest developments in green building, research, and reports from the field.

Replies

  1. GBA Editor
    Martin Holladay||#1

    大卫,
    Do you have a code reference or code citation? I have never heard of a barometric damper being used for this purpose.

  2. David Meiland||#2

    马丁,在这里。这是来自华盛顿州立法网站的,我认为是IMC的一部分...http://app.leg.wa.gov/wac/default.aspx?cite=51-51-1006

    Exception 2 is what would apply in this case.

    What I recall hearing of, and am hoping to find, is something that incorporates some sort of fabric "bladder" inside a short piece of duct. I've talked to a fairly large number of people so far without any hits.

  3. GBA Editor
    Martin Holladay||#3

    大卫,
    Here is a link to the type of damper you are talking about (it's called the Cape Damper, and it's made by Tamarack Technologies):
    Tamarack Cape Backdraft Damper

    Although I'm confident that this is the product you are talking about, I'm not sure whether it's the type of damper that the code writers had in mind for the purpose you intend.

  4. GBA Editor
    Martin Holladay||#4

    By the way, Tamarach Technologies is a good company that makes quality products -- but they get a demerit for their cheesy choice of a photo to illustrate their web page that sells backdraft dampers.

    .

  5. David Meiland||#5

    Martin, you guys could use images like that on GBA and receive a lot more web traffic...

    I think I'll run the Tamarack product by the building inspector and see what he thinks.

  6. GBA Editor
    Martin Holladay||#6

    大卫,
    我在最长的时间里看了沙发的照片 - 但我仍然找不到背景阻尼器。也许是那些大白色垫子之一。
